WD Purple 14TB Surveillance Hard Drive — Extended-Retention Storage for Chicago NVR Builds
Model / Series: WD142PURZ
14 TB surveillance hard drive rated for 24/7 NVR duty — the size we install when a 16-camera 4K system needs 90-day retention.
We don't just ship boxes — this goes in as part of our security camera installation in Chicago work. Inheriting a half-working setup from a previous vendor? Start with a security system takeover.
Specifications
- Brand
- Western Digital
- Model
- WD142PURZ
- Series
- WD Purple
- Type
- Surveillance-rated hard drive
- Capacity
- 14 TB
- Form Factor
- 3.5-inch SATA
- Interface
- SATA 6 Gb/s
- RPM
- 7,200 RPM
- Cache
- 512 MB
- Workload
- Up to 360 TB/year
- Camera Support
- Up to 64 cameras
- Special Features
- WD AllFrame AI technology
- MTBF
- 1,500,000+ hours
- Warranty
- 3 years
- Operating Temperature
- 0 °C to +65 °C
Best Fit & Recommended For
WD Purple 14TB — Extended-Retention Surveillance Drive
The WD Purple 14TB is a higher-capacity drive from Western Digital’s WD Purple line — featuring AllFrame AI technology, 512 MB cache, 7,200 RPM, 360 TB/year workload, MTBF 1,500,000+ hours, 3-year warranty.
The 14 TB size covers 32-camera NVR builds and 16-camera 4K systems that need 90+ days of footage — typical pairings with the QRN-1630S, XRN-820S, and XRN-3220B2 NVRs.
Where the WD Purple 14TB Fits
- 32-camera NVR builds with 60-90 day retention
- 16-camera 4K NVR with 90+ day retention
- Condo and HOA buildings where the board wants months of footage, not weeks
- Warehouse NVRs recording docks and aisles around the clock
- Property management portfolios standardizing on one drive size
- Parking garages where the cameras never stop writing
Local Chicago Coverage
Vidimost installs WD Purple 14 TB drives across the full city of Chicago for extended-retention NVR projects.
Recommended NVR Pairings
- Hanwha QRN-1630S — Q-series 16-channel with 20 TB HDD support (14 TB fits comfortably)
- Hanwha XRN-820S — X-series 8-channel flagship with multi-bay
- Hanwha XRN-3220B2 — X-series 32-channel with 8 HDD bays
Professional Installation by Vidimost
When a condo board asks for three months of footage instead of three weeks, this is usually the drive that makes the math work. Vidimost LLC installs WD Purple 14 TB in NVR builds across Chicago. Contact us for a free site walkthrough and quote.
