Ubiquiti UniFi PoE Adapter 15W (U-PoE) — 48V Single-Port PoE Injector for Chicago

Ubiquiti UniFi PoE Adapter 15W (U-PoE)

The Ubiquiti UniFi PoE Adapter (model U-PoE) is a 15 W passive single-port PoE injector — the entry-level Ubiquiti PoE injector for low-power UniFi access points and IP cameras. 48 V DC @ 0.32 A output, 15 W total, gigabit LAN port, NDAA-compliant. We keep a couple on the truck for jobs where the closet switch has no PoE left and one AP still needs power.

What’s Confirmed by the Official Ubiquiti Spec

These specifications come directly from store.ui.com’s published U-PoE product page:

• Model: U-PoE
• Output: 48 V DC @ 0.32 A — 15 W total
• Input: 100–240 V AC at 50/60 Hz; max input current 500 mA
• Data port: Gigabit LAN, RJ45 shielded socket
• Powering method: 2-pair — pins 4, 5 (+) and 7, 8 (−)
• Efficiency: 84.25%+
• Switching frequency: 65 kHz
• Operating temperature: 0 to 40 °C
• Surge protection: surge, peak pulse, and overcurrent; clamping 11 V data, 60 V power; max surge discharge 1500 A (8/20 μs)
• Dimensions: 86 × 46 × 33 mm (3.4 × 1.8 × 1.3 in)
• Weight: 100 g (3.5 oz)
• AC connector: IEC-320 C6
• NDAA-compliant: Yes
• Certifications: CE, FCC, IC, UL, CCC

When U-PoE 15W Fits — Low-Power UniFi Devices

Pick the U-PoE 15W when:

• The device is a low-power UniFi access point (e.g., older U6-series APs, small wall-plate APs)
• The protected load is under 15 W
• A single-port injector is sufficient (no need for a multi-port PoE switch)
• The site doesn’t have a PoE-capable network switch or has a fully-utilized PoE budget on the existing switch

For higher-power UniFi devices (modern U6-Pro, U7 APs, PTZ cameras, larger speakers), step up to one of the higher-wattage Ubiquiti PoE adapters:

• Ubiquiti UniFi PoE+ 30W (U-PoE+) — 802.3at-class power
• Ubiquiti UniFi PoE++ 60W (U-PoE++) — 802.3bt Type 3
• Ubiquiti 10G PoE+++ 90W (UACC-PoE+++-10G) — 802.3bt Type 4 with multi-gig data

Ubiquiti PoE Adapter Family Comparison

Model	Wattage	Voltage / Current	Best Fit
U-PoE (this page)	15 W	48 V @ 0.32 A	Low-power UniFi APs, small IP cameras
U-PoE+	30 W	48 V @ 0.65 A	Standard UniFi APs, mid-range cameras
U-PoE++	60 W	48 V @ 1.25 A	Higher-power APs, PTZ cameras
UACC-PoE+++-10G	90 W	54 V @ 1.67 A	Top-tier UniFi devices needing multi-gig data + max power

Where the Ubiquiti U-PoE 15W Wins in Chicago

• Commercial UniFi access point single-port power
• Low-power IP camera installations without PoE switch availability
• Small office single-AP deployment
• Multi-tenant residential lobby AP installation
• Café / restaurant guest Wi-Fi single-AP power
• Condo amenity room single-AP installation
• Retail single-storefront AP power
• Property management single-AP retrofits
• Construction site office single-AP deployment

Local Chicago Coverage

Vidimost installs the Ubiquiti U-PoE 15W across the full city of Chicago for low-power single-port PoE injection.

Recommended Pairings

• Ubiquiti UniFi PoE+ 30W — next-tier-up sibling for standard APs
• Ubiquiti UniFi PoE++ 60W — higher-power devices
• Ubiquiti 10G PoE+++ 90W — top-tier with multi-gig data
• UniFi access points / cameras (specified per project)

Professional Installation by Vidimost

Vidimost LLC installs the Ubiquiti U-PoE 15W across Chicago for single-port low-power UniFi deployments. Full-scope service includes site walkthrough, device-power verification (under 15 W), CAT5e/CAT6 cabling between injector and device, AC primary placement, and integration with the broader UniFi network. Contact us for a free site walkthrough and quote.
