HID iCLASS SE R15 Reader — Single-Gang Mid-Size Smart Card Reader for Chicago Standard Wall Smart Card Deployments
Model / Series: iCLASS SE R15
The HID iCLASS SE R15 is a single-gang mid-size contactless smart card reader supporting iCLASS SE and SEOS 13.56 MHz credentials with cryptographic mutual authentication. Mid-size form factor between the compact mullion R10 and the larger R40 — for Chicago commercial deployments needing single-gang installation at moderate profile.
We don't just ship boxes — this goes in as part of our access control installation in Chicago work. From the Loop to Rogers Park — see our security work across Chicago.
Specifications
- Brand
- HID Global
- Model
- iCLASS SE R15
- Series
- HID iCLASS SE
- Form Factor
- Single-gang (mid-size)
- Card Technologies Supported
- iCLASS SE, SEOS, MIFARE Classic, MIFARE DESFire EV1/EV2 (13.56 MHz)
- Frequency
- 13.56 MHz contactless smart card
- Authentication
- Mutual authentication + encrypted data exchange (iCLASS SE)
- Communication Protocol
- Wiegand (legacy) — OSDP available with adapters
- Operating Temperature
- −35 °C to +66 °C
- Environmental Protection
- IP55 (indoor / protected outdoor)
- Mounting
- Standard US single-gang electrical box
Best Fit & Recommended For
HID iCLASS SE R15 — Single-Gang Mid-Size Smart Card Reader
The HID iCLASS SE R15 is the single-gang mid-size reader from HID Global’s iCLASS SE platform — supporting iCLASS SE and SEOS 13.56 MHz credentials with cryptographic mutual authentication. Mid-size form factor between the compact mullion R10 and the larger R40 — Wiegand output, IP55-rated.
When to Choose R15 vs. Sibling iCLASS SE Readers
| Form factor | Model | Best fit |
|---|---|---|
| Mullion (smallest) | R10 | Elevators, narrow frames |
| Single-gang (mid-size) | R15 (this) | Standard single-gang mid-profile |
| Standard wall (larger) | R40 | Most commercial doors |
| Long-range | R90 | Vehicle gates, parking |
Where the iCLASS SE R15 Wins in Chicago
- Chicago commercial office single-gang smart card positions
- HOA single-gang door entries with iCLASS SE / SEOS at Chicago HOAs
- Multi-tenant residential standard wall positions — Loop, River North, Mag Mile high-rises
- Healthcare clinic standard-wall door positions
- Education facility standard administrative + corridor doors
- Property management common-area door readers
- Hospitality back-of-house door positions
Local Chicago Coverage
Vidimost installs the HID iCLASS SE R15 across the full city of Chicago.
Recommended Pairings
- HID iCLASS SE R10 — for narrow-frame positions
- HID iCLASS SE R40 — for larger standard wall
- HID multiCLASS SE RP15 — multi-tech (iCLASS SE + Prox)
- HID Signo 40 — full multi-tech + mobile
Professional Installation by Vidimost
Vidimost LLC is an active HID Global installer across Chicago. The iCLASS SE R15 is our mid-size single-gang smart card reader pick. Full-scope service includes site walkthrough, credential platform planning, Wiegand wiring, single-gang mounting, reader commissioning, controller configuration, and operator training. Contact us for a free site walkthrough and quote.
